不同潔凈度等級的潔凈區的劃分原則
- 發布人：
- 發布日期：2017-04-13 17:50:00
在確定潔凈區劃分原則時，首先需要確定保護對象
In determining the principle of division of the clean area, the first need to determine the protection object
1） 保護生產過程（產品）不受人員和環境污染；
1) to protect the production process (product) without the personnel and environmental pollution;
2） 保護人員（環境）不受生產過程污染；
2) the protection of persons (environment) is not subject to the process of production;
3） 防止生產過程與人員（環境）相互污染，即要綜合防護，1）和2）兩項同時要采用。
3) to prevent the production process and personnel (environment) mutual pollution, namely to comprehensive protection, 1) and two, while the use of.
如果要求采用隔離（屏障）工藝，即必須采用物理屏障密閉局部潔凈區，這樣就需要隔離：
If the requirements of the use of isolation (barrier) process, that is, the physical barrier must be confined to the clean area, which requires isolation:
1. 使生產過程與周?chē)h(huán)境（人員）隔離；
1 to isolate the production process and the environment (personnel);
2. 使環境、人員與生產過程隔離；
2 isolate the environment, personnel and production process;
潔凈室技術被廣泛應用于保護生產過程（產品），不受人員和環境污染。為此需遵循下列三項原則之一：
Clean room technology is widely used in the protection of the production process (product), not the personnel and environmental pollution. One of the following three principles should be followed:
1.使?jié)崈羰冶３直揉徑块g更高的氣壓；
Make clean room maintain pressure of 1 neighboring room more;
2.在潔凈區與較不潔凈區的分界處應保持較高的排風風速；
2 in the clean area and the relatively clean area of the boundary should be maintained at a high speed of the wind;
3.采用物理隔離的方式隔離不同的區域。
3 separate different regions by means of physical isolation.
壓差原則就是防止較不潔凈區的氣流向潔凈區倒灌（例如通過門縫），即在潔凈室內保持恒定的高壓（５～２０Ｐａ）。其氣流組織原則是低速氣流由潔凈室向著鄰近區域并保持相對高的壓差。受控參數就是壓差。
Pressure difference principle is to prevent the air is not clean area to the clean area intrusion (for example through the crack of the door), namely in the clean room maintain a constant pressure (5 ~ 20). The principle of the air flow organization is that the low velocity air flow is from the clean room to the adjacent area and remains relatively high. Controlled parameter is differential pressure.
排風原則就是形成低渦流或近似于單向氣流，風速大于０．２米／秒，由較潔凈區吹向較不潔凈區，以防止氣流倒灌。
Exhaust principle is the formation of vortex flow or similar to the unidirectional air flow velocity is greater than 0.2 M / sec, by the relatively clean area blow to a clean area to prevent Backdraught airflow.
在應用此種方式時，應考慮到障礙物，熱源和污染物，排風格柵位置等的影響。此項原則的特點就是低壓差，相對高的氣流風速。運用此項原則的實例就是位于較低潔凈度級別房間內的層流潔凈區（單向氣流區）。
In the application of this method, the influence of the obstacle, heat source and pollutant, and the position of the wind grid should be considered. This principle is characterized by low pressure, relatively high airflow speed. Examples of the use of this principle is at a relatively low level of cleanliness in the room clean area (one-way flow area).
區域的物理分隔原則就是建立隔離裝置，對由較低潔凈度的房間產生的污染形成不可逾越的屏障，不致進入較高潔凈度的潔凈室。
Area of physical separation principle is to establish isolation device, impassable for the formation of the pollution produced by the low cleanliness of the room the barrier, not into a high cleanliness of clean room.
如果是具有有害物的生產過程（個別品種的致病微生物，強烈反應的化學制劑），則應保證該處的氣壓相對于環境是負壓。
If there is a production process (individual species of pathogenic microorganisms, the strong reaction of the chemical agents), then should ensure that the pressure in the area is negative pressure.
應予指出，建立負壓的要求是與潔凈室的工作原理相矛盾的，潔凈室是基于正壓差的。為了解決此項矛盾，便采用了另加的氣閘室，在潔凈室周?chē)⒌诙用荛]外殼（包括吊頂）使氣閘室相對于鄰近房間和有害作業具有高的正壓。
It should be pointed out that the requirement to establish negative pressure is in contradiction with the working principle of the clean room, clean room is based on the positive pressure difference. In order to solve this contradiction, adopt the plus the airlock, in clean room around the establishment of the second layer of the closed shell (including ceiling) the airlock relative to adjacent rooms and hazardous operation has high positive pressure.
為此，就可以采用隔離工藝，例如，在接觸有毒制劑時采用具有負壓得隔離裝置。
To this end, the separation process can be used, for example, the use of a negative pressure isolation device when exposed to toxic agents.
